Endurace CF 7 Di2

Frame

• Frame
  • Canyon Endurace CF Disc
  • Comfortable carbon road frame with Canyon's hallmark relaxed-yet-responsive Sport geometry.
  • Axle dimension: 12x142 mm
  • Tyre clearance: 35 mm
  • Material: Carbon (CF)
  • Weight: 2.45 lbs
• Fork
  • Canyon FK0110 CF Disc
  • Superlight carbon fork, engineered for high stiffness-to-weight and compliance.
  • Axle dimension: 12x100 mm
  • Fork steer tube diameter: 1 1/8"
  • Tyre clearance: 36 mm
  • Material: Carbon (CF)
  • Weight: 1.12 lbs

Drivetrain

• Battery
  • Shimano BT-DN300 Di2 Battery
• Rear Derailleur
  • Shimano 105 Di2 groupset
  • Weight: 0.66 lbs
• Front Derailleur
  • Shimano 105 Di2 FD-R7150
  • Weight: 0.30 lbs
• Cassette
  • Shimano CS-HG710 11-36 12s
  • Number of sprockets: 12
  • Range: 11-36
• Crank
  • Shimano 105 R7100
  • Number of chainrings: 2
• Bottom bracket
  • Shimano Pressfit BB72
  • Bottom bracket standard: PF 86,5
  • Weight: 0.14 lbs
• Chain
  • Shimano CN-M7100 12s

Brakes

• Shift-/ Brake Lever
  • Shimano 105 Di2 R7170, 12-speed
  • Number of pistons: 2
  • Weight: 0.86 lbs
• Shift-/ Brake Lever
  • Shimano 105 Di2 R7170, 12-speed
  • Number of pistons: 2
  • Weight: 0.85 lbs
• Brake Rotor
  • Shimano SM-RT70
  • Size: 160 mm
  • Weight: 0.32 lbs

Wheels

• Wheel
  • DT Swiss ERC 1600 Dicut HG
  • Axle dimension: 12x142 mm
  • Rotor mount: Center Lock
  • Rim height: 35 mm
  • Inner width: 22 mm
  • Rim material: Carbon
  • Weight: 1.97 lbs
• Wheel
  • DT Swiss ERC 1600 Dicut
  • Axle dimension: 12x100 mm
  • Rotor mount: Center Lock
  • Rim height: 35 mm
  • Inner width: 22 mm
  • Rim material: Carbon
  • Weight: 1.63 lbs
• Tyre
  • Schwalbe Pro One TLE, 30mm
  • High-end road tyre that combines suppleness, speed, and control at the highest level.
  • Tech: tubeless-ready, v-guard puncture protection
  • Compound: Addix Race
  • On certain models, this tire may be substituted for an alternate, equivalent Schwalbe model.
  • Potentially affected models include:
  • Endurace CF SLX 9 Di2 (Model #3369)
• Tyre
  • Schwalbe Pro One TLE, 32mm
  • On certain models, this tire may be substituted for an alternate, equivalent Schwalbe model.
  • Potentially affected models include:
  • Endurace CF SLX 9 Di2 (Model #3369)
• Thru Axle
  • Canyon GP0197-01
  • Axle dimension: 12x100 mm
• Thru Axle
  • Canyon GP0235-01
  • Axle dimension: 12x142 mm

Cockpit

• Cockpit
  • Canyon CP0030 Aerocockpit
