Aeroad CFR AXS

ADD TO CART
BUY IT NOW
  • Detail

    Frame

    • Frame
      • Canyon Aeroad CFR
      • Fourth-generation Aeroad frame uniting peloton-leading aerodynamics with an improved carbon layup for added robustness.
      • Axle dimension: 12x142 mm
      • Front derailleur hanger: removable
      • Tyre clearance: 32 mm
      • Material: Carbon (CFR)
      • Weight: 2.19 lbs
    • Fork
      • Canyon FK0137 CF Disc
      • Aero fork shaped using advanced CFD technology. With hermetically sealed headset and titanium bearing seat for next-level durability and smoothness.
      • Axle dimension: 12x100 mm
      • Fork steer tube diameter: 1 1/8"
      • Tyre clearance: 32 mm
      • Material: Carbon (CF)
      • Weight: 0.87 lbs

    Drivetrain

    • Battery
      • SRAM Powerpack
    • Rear Derailleur
      • SRAM Red AXS Rear Derailleur
      • Weight: 0.58 lbs
    • Front Derailleur
      • SRAM Red
      • Weight: 0.32 lbs
    • Cassette
      • SRAM RED XG-1290
      • Number of sprockets: 12
      • Range: 10-28
    • Crank
      • SRAM Red
      • Number of chainrings: 2
    • Bottom bracket
      • Ceramicspeed Coated BB (SRAM)
      • Bottom bracket standard: PF 86,5
      • Weight: 0.17 lbs
    • Chain
      • SRAM RED

    Brakes

    • Shift-/ Brake Lever
      • SRAM Red
      • Number of pistons: 2
      • Weight: 0.80 lbs
    • Shift-/ Brake Lever
      • SRAM Red
      • Number of pistons: 2
      • Weight: 0.80 lbs
    • Brake Rotor
      • SRAM Paceline X
      • Size: 160 mm
      • Weight: 0.30 lbs
    • Brake Rotor
      • SRAM Paceline X
      • Size: 140 mm
      • Weight: 0.24 lbs

    Wheels

    • Wheel
      • DT Swiss ARC 1100 Dicut db
    • Wheel
      • DT Swiss ARC 1100 Dicut db
      • Axle dimension: 12x100 mm
      • Rotor mount: Center Lock
      • Rim height: 50 mm
      • Inner width: 20 mm
      • Rim material: Carbon
      • Weight: 1.56 lbs
    • Wheel
      • DT Swiss ARC 1100
      • Axle dimension: 12x142 mm
      • Rotor mount: Center Lock
      • Rim height: 50 mm
      • Inner width: 20 mm
      • Rim material: Carbon
      • Weight: 1.88 lbs
    • Tyre
      • Continental Aero 111
      • Width: 26 mm
      • Weight: 0.54 lbs
    • Tyre
      • Continental Grand Prix 5000 S TR, 28mm
      • Width: 28 mm
      • Weight: 0.65 lbs
    • Thru Axle
      • DT Swiss Through Axle
      • Axle dimension: 12x142 mm
    • Thru Axle
      • DT Swiss Through Axle
      • Axle dimension: 12x100 mm

    Cockpit

    • Cockpit
